AR400 VS AR500 Steel

Published on: July 12, 2023
huaxiaometal

AR400 vs AR500 steel are two popular types of abrasion-resistant steels used in various industries. They possess unique properties that make them suitable for applications requiring resistance to wear and tear. This article aims to explore the similarities and differences between AR400 vs AR500 steels, providing a comprehensive comparison of their characteristics and applications.

Request A Quote

What is Abrasion Resistant Steel?

AR steel is a high-carbon steel alloy that has been hardened and tempered to a very high surface hardness. This hardness makes it very resistant to wear from sliding and impact. The number in its name, such as “400” or “500,” usually represents its nominal Brinell hardness (BHN).

Definition and Composition: AR400 VS AR500 Steel

What is AR400 Steel?

AR400 steel is a type of wear-resistant steel that is known for its high hardness and durability. It is specifically designed to resist wear and abrasion caused by contact with rough materials, such as rocks, gravel, ores, and other abrasive substances. AR400 steel is commonly used in applications where the material needs to withstand heavy wear and impact, such as in mining equipment, dump truck bodies, excavator buckets, and conveyor systems.

What is AR500 Steel?

AR500 steel is a type of hardened, wear-resistant steel known for its exceptional toughness and resistance to wear. It is specifically designed to withstand heavy impacts and high levels of abrasion, making it suitable for applications where the material needs to endure extreme conditions.

AR500 steel derives its name from its hardness level, which typically falls within the range of 470 to 540 Brinell Hardness Number (BHN). This high hardness provides superior resistance against penetration, allowing the steel to withstand the impact of projectiles, bullets, and other objects with minimal deformation or damage.

AR400 VS AR500 Steel Composition

	C	Mn	P	S	Si	Cr	Ni	Other
AR400 Steel	0.30-0.40%	1.00-1.50%	0.025% max	0.025% max	0.15-0.40%	–	–	–
AR500 Steel	0.30-0.40%	1.20-1.60%	0.025% max	0.025% max	0.15-0.40%	0.70-0.90%	0.20-0.40%	–

Hardness and Strength: AR400 VS AR500 Steel

AR400 Steel:
- Hardness: AR400 has a hardness range of 360-440 BHN, providing good resistance against abrasive forces.
- Strength: It exhibits excellent impact toughness, making it suitable for applications subjected to repeated impacts.
AR500 Steel:
- Hardness: AR500 steel possesses a hardness range of 470-540 BHN, which offers superior resistance against heavy wear and penetration.
- Strength: Its high hardness provides exceptional resistance to deformation and cracking, making it ideal for high-impact applications.

Applications: AR400 VS AR500 Steel

1.AR400 Steel:

- - Common Applications: AR400 steel finds application in industries such as mining, construction, agriculture, and forestry.
  - Examples: It is used for wear liners, buckets, blades, hoppers, and other equipment exposed to abrasive materials.

2.AR500 Steel:

- - Common Applications: AR500 steel is often utilized in industries where extreme wear resistance is required.
  - Examples: It is used for targets, armored vehicles, shooting range equipment, and applications involving ballistic protection.

Weldability and Fabrication: AR400 VS AR500 Steel

AR400 Steel:
- Weldability: AR400 steel can be welded using conventional methods, but precautions need to be taken to avoid heat-affected zone (HAZ) issues.
- Fabrication: It can be easily cut, formed, and machined to suit various requirements.
AR500 Steel:
- Weldability: AR500 steel requires special precautions during welding due to its higher hardness and susceptibility to cracking.
- Fabrication: It is more challenging to cut and form compared to AR400, but it can be achieved with appropriate equipment and techniques.

FAQ: AR400 VS AR500 Steel

Can AR500 steel be welded?

Yes, but the process must be strictly followed. Due to the high carbon content of AR500 steel, low-hydrogen welding materials need to be used when welding, and sufficient preheating (usually 150°C-200°C) and slow post-weld cooling are required to prevent welding cracks. We provide detailed welding procedure guidance to all customers. If you have any questions, please contact us directly!

Is AR500 always better than AR400?

Not really. This is a typical “cost-performance” trade-off. If the impact load in your application scenario is much greater than the sliding wear, or complex cold bending forming is required, then AR400, which has better toughness and is easier to process, is a more economical and reliable choice.

How thick should I choose the steel plate?

The choice of thickness depends on the specific impact force, material type and structural design. This is a question that requires professional calculation. Our technical team can provide you with professional calculations and recommendations based on the working parameters you provide.

How much more expensive is AR500 than AR400?

Generally, the unit price of AR500 steel plate will be 15%-30% higher than AR400, depending on market conditions, steel mills and thickness. However, the “full life cycle cost” should be considered when evaluating, including replacement frequency and downtime losses.

In conclusion

AR400 vs AR500 steels are both excellent choices for applications demanding resistance to abrasion and wear. While AR400 offers a good balance of hardness and toughness, AR500 provides enhanced hardness and penetration resistance. Understanding the differences between these two steels enables industry professionals to select the appropriate material based on specific requirements, ensuring optimal application performance and longevity.
