Quality Stainless Steel Tube Suppliers
Stainless Steel Tube Specification
As one of the leading stainless steel tube suppliers in China, Huaxiao Metal Co., Ltd. takes pride in providing high-quality stainless steel pipe products to our customers. The following are the ss pipe specifications we can provide.
- 1. Material: stainless steel (typical grades such as 304, 316, 316L, 2205, etc.)
- 2. Dimensions: Outer Diameter (OD) x Wall Thickness (WT) x Length
- 3. Standard: ASTM, ASME, EN, DIN, JIS, or other international standards
- 4. Manufacturing method: seamless or welded
- 5. Surface treatment: annealing, pickling, polishing, etc.
- 6. Application: industry, construction, automobile, etc.
Table of Contents
Classification of Stainless Steel Pipes
Stainless steel pipes can be classified based on their manufacturing process, material composition, and shape. Here’s a breakdown of each classification:
a. Stainless Steel Round Tubes: The most common shape used in various applications.
b. Stainless Steel Square Tubes: Used for structural and ornamental purposes.
c. Stainless Steel Rectangular Tubes: Also used for structural and decorative applications.
d. Oval Stainless Steel Tubes: These have an elliptical cross-section and find use in special applications like handrails and exhaust systems.
a. Seamless Stainless Steel Pipes: These pipes are manufactured without any welding joints, resulting in a smooth interior surface. They are produced through a hot or cold drawing process.
b. Stainless Steel Welded Pipes: These pipes are formed by welding stainless steel plates or coils together. They can be further classified into:
- – Longitudinal Welded Pipes: Welded along the length of the pipe.
- – Spiral Welded Pipes: Manufactured by helically welding coiled steel.
- – Electric Resistance Welded (ERW) Pipes: Produced by welding using electric resistance.
a. Austenitic Stainless Steel Pipes: The most commonly used type, known for their excellent corrosion resistance and high ductility. Examples include grades like 304 and 316.
b. Ferritic Stainless Steel Pipes: Have higher chromium content and lower carbon content, offering good corrosion resistance and moderate strength. Grade 409 is an example.
c. Martensitic Stainless Steel Pipes: These pipes have high hardness and strength but lower corrosion resistance compared to austenitic grades. Grade 410 is an example.
d. Duplex Stainless Steel Pipes: Combining characteristics of both austenitic and ferritic stainless steels, they offer high strength and better resistance to stress corrosion cracking. Grade 2205 is an example.
Classification Based On Shape:
Stainless Steel Round Tubes
The size range of Stainless Steel Round Tubes can vary depending on the specific manufacturing standards and requirements of different industries. However, here is a generalized list of common size ranges for Stainless Steel Round Pipes:
Outer Diameter (OD):
- Small Diameter: 1/8″ (3.175 mm) to 1″ (25.4 mm)
- Medium Diameter: 1″ (25.4 mm) to 12″ (304.8 mm)
- Large Diameter: 12″ (304.8 mm) and above
Wall Thickness (WT):
- Thin Wall: 0.028″ (0.71 mm) to 0.065″ (1.65 mm)
- Standard Wall: 0.065″ (1.65 mm) to 0.154″ (3.91 mm)
- Thick Wall: 0.154″ (3.91 mm) and above
Please note that these size ranges are for guidance only. Please contact the stainless steel round tube manufacturer or supplier for exact information on available sizes and specifications.
Stainless Steel Square Tubes
The size range of Stainless Steel Square Tubes can vary depending on the specific manufacturing standards and requirements of different industries. However, here is a generalized list of common size ranges for Stainless Steel Square Tubes:
Outer Dimensions (Width x Height):
- – Small Size: 1/2″ x 1/2″ (12.7 mm x 12.7 mm) to 1″ x 1″ (25.4 mm x 25.4 mm)
- – Medium Size: 1″ x 1″ (25.4 mm x 25.4 mm) to 4″ x 4″ (101.6 mm x 101.6 mm)
- – Large Size: 4″ x 4″ (101.6 mm x 101.6 mm) and above
Wall Thickness (WT):
- – Thin Wall: 0.028″ (0.71 mm) to 0.065″ (1.65 mm)
- – Standard Wall: 0.065″ (1.65 mm) to 0.154″ (3.91 mm)
- – Thick Wall: 0.154″ (3.91 mm) and above
Please note that these size ranges are for guidance only. Please contact the stainless steel square tube manufacturer or supplier for exact information on available sizes and specifications.
Stainless Steel Rectangular Tubes
The size range of Stainless Steel Rectangular Tubes can vary depending on the specific manufacturing standards and requirements of different industries. However, here is a generalized list of common size ranges for Stainless Steel Rectangular Tubes:
Outer Dimensions (Width x Height):
- Small Size: 1/2″ x 1″ (12.7 mm x 25.4 mm) to 1″ x 2″ (25.4 mm x 50.8 mm)
- Medium Size: 1″ x 2″ (25.4 mm x 50.8 mm) to 4″ x 6″ (101.6 mm x 152.4 mm)
- Large Size: 4″ x 6″ (101.6 mm x 152.4 mm) and above
Wall Thickness (WT):
- Thin Wall: 0.028″ (0.71 mm) to 0.065″ (1.65 mm)
- Standard Wall: 0.065″ (1.65 mm) to 0.154″ (3.91 mm)
- Thick Wall: 0.154″ (3.91 mm) and above
Please note that these size ranges are for guidance only. Please contact the stainless steel rectangular tube manufacturer or supplier for exact information on available sizes and specifications.
Oval Stainless Steel Tubes
The size range of Oval Stainless Steel Tubes can vary depending on the specific manufacturing standards and requirements of different industries. However, here is a generalized list of common size ranges for Oval Stainless Steel Tubes:
Outer Dimensions (Width x Height):
- Small Size: 0.5″ x 1″ (12.7 mm x 25.4 mm) to 1″ x 2″ (25.4 mm x 50.8 mm)
- Medium Size: 1″ x 2″ (25.4 mm x 50.8 mm) to 3″ x 6″ (76.2 mm x 152.4 mm)
- Large Size: 3″ x 6″ (76.2 mm x 152.4 mm) and above
Wall Thickness (WT):
- Thin Wall: 0.028″ (0.71 mm) to 0.065″ (1.65 mm)
- Standard Wall: 0.065″ (1.65 mm) to 0.154″ (3.91 mm)
- Thick Wall: 0.154″ (3.91 mm) and above
Please note that these size ranges are for guidance only. Please contact the oval stainless steel pipe manufacturer or supplier for exact information on available sizes and specifications.
Classification Based On Manufacturing Process:
Seamless Stainless Steel Pipes
The size range of Seamless Stainless Steel Pipes can vary depending on the specific manufacturing standards and requirements of different industries. However, here is a generalized list of common size ranges for Seamless Stainless Steel Pipes:
Outer Diameter (OD):
- – Small Diameter: 1/8″ (3.175 mm) to 1″ (25.4 mm)
- – Medium Diameter: 1″ (25.4 mm) to 12″ (304.8 mm)
- – Large Diameter: 12″ (304.8 mm) and above
Wall Thickness (WT):
- – Thin Wall: 0.028″ (0.71 mm) to 0.065″ (1.65 mm)
- – Standard Wall: 0.065″ (1.65 mm) to 0.154″ (3.91 mm)
- – Thick Wall: 0.154″ (3.91 mm) and above
Please note that these size ranges are for guidance only. Please contact the stainless steel seamless pipe manufacturer or supplier for exact information on available sizes and specifications.
Stainless Steel Welded Tubes
The size range of Stainless Steel Welded Tubes can vary depending on the specific manufacturing standards and requirements of different industries. However, here is a generalized list of common size ranges for Stainless Steel Welded Tubes:
Outer Diameter (OD):
- – Small Diameter: 1/8″ (3.175 mm) to 1″ (25.4 mm)
- – Medium Diameter: 1″ (25.4 mm) to 12″ (304.8 mm)
- – Large Diameter: 12″ (304.8 mm) and above
Wall Thickness (WT):
- – Thin Wall: 0.028″ (0.71 mm) to 0.065″ (1.65 mm)
- – Standard Wall: 0.065″ (1.65 mm) to 0.154″ (3.91 mm)
- – Thick Wall: 0.154″ (3.91 mm) and above
Please note that these size ranges are for guidance only. Please contact the stainless steel welded tube manufacturer or supplier for exact information on available sizes and specifications.
Classification Based On Grade:
316 Stainless Steel Tubes
316 stainless steel tubes are a type of stainless steel pipe that is made from the alloy 316, which is a popular grade of stainless steel known for its excellent corrosion resistance and high-temperature strength. These pipes are widely used in various industries and applications where resistance to corrosion and chemical exposure is essential.
Please contact the 316 stainless steel tube supplier or manufacturer for exact information on available sizes and specifications.
304 Stainless Steel Tubes
304 stainless steel tubes are a type of stainless steel tubing made from the alloy 304, which is one of the most commonly used and widely available grades of stainless steel. These tubes are known for their excellent corrosion resistance, versatility, and ease of fabrication, making them suitable for various applications across different industries.
Please contact the 304 stainless steel tube supplier or manufacturer for exact information on available sizes and specifications.
Duplex Stainless Steel Pipes
Duplex stainless steel pipes are a type of stainless steel pipe that belongs to the family of duplex steels. Duplex stainless steels are a combination of both austenitic and ferritic stainless steels, offering a unique set of properties that make them highly suitable for specific applications, especially in environments where both high strength and corrosion resistance are required.
Please contact the duplex stainless steel pipe supplier or manufacturer for exact information on available sizes and specifications.
Why Choose Huaxiao As Your Stainless Steel Tube Suppliers
As one of the stainless steel tube suppliers in China, we at Huaxiao Metal Corporation Limited take great pride in providing high-quality stainless pipe products to our customers. Here are some reasons why we believe you should choose us as your stainless steel tube suppliers:
- Wide range of stainless steel pipe products: As an experienced stainless steel pipe supplier, we offer a wide range of stainless steel pipe products to meet the diverse needs of our customers. We provide various alloys, sizes, and thicknesses of stainless tubes to ensure that our customers can find the products they need.
- High-quality stainless steel pipe products: We have strict quality control procedures in place to ensure that our stainless steel tube products meet the required quality standards. We have advanced equipment and technology to produce high-quality ss pipes.
- Competitive pricing: We offer competitive pricing for our ss pipe products without compromising on quality. We strive to offer flexible pricing options to meet the needs and budgets of our customers.
- Efficient logistics: We have an efficient logistics system that ensures fast and reliable delivery of stainless tube products to our customers. We have a reliable transportation network that ensures the timely delivery of products to customers around the world.
- Excellent customer service: We have a team of dedicated professionals who provide excellent customer service. We are always available to answer customer queries, offer technical support, and provide after-sales service.
Stainless Steel Tube Stock
Package of Stainless Steel Pipes
We are one of the professional stainless steel tube suppliers in China, committed to providing customers with high-quality products and services. As a trustworthy supplier, we attach great importance to the packaging of stainless steel pipes to ensure that the product is not damaged during transportation.
As one of the stainless steel tube suppliers in China with many years of experience, our professional team will do our best to provide customers with the best products and services. We know that every detail matters to our customers, so we keep improving our services to meet our customers’ needs. We look forward to working with you to provide you with the best stainless steel pipe and related services.
Contact Us for Stainless Steel Tube Price
Huaxiao Metal provides a wide range of welded and seamless stainless steel pipes to meet your application requirements. We also offer rectangular steel tubing, square tubing, and round tubing in stainless steel and other materials. Request a quote for your steel pipes today.
